Item | Unit | Value | |
Working performance | Max. rated lifting capacity | kg | 80000 |
Max. load moment of basic boom | kN.m | 2575 | |
Max. load moment of main boom(fully extended) | kN.m | 1240 | |
Max. load moment of basic boom | m | 12.2 | |
Max. lifting height of main boom | m | 44.2 | |
Max. lifting height of jib | m | 60.2 | |
Working speeds | Max. hoist rope speed(Main winch) | m/min | ≥135 |
Max. hoist rope speed(Auxiliary winch) | m/min | ≥110 | |
Boom demrricking up time | s | 57 | |
Boom demrricking up time | s | 107 | |
Slewing speed | r/min | 1.8 | |
Driving | Max. driving speed | km/h | 75 |
Max. gradeability | % | 37 | |
Turning diameter | m | 24 | |
Min. ground clearance | mm | 280 | |
Oil consumption per hundred kilometers | L | 46 | |
Mass | Deadweight in driving condition | kg | 45000 |
Complete vehicle kerb mass | kg | 44870 | |
Front axle load | kg | 19000 | |
Rear axle load | kg | 26000 | |
Dimension | Overall dimensions(L×W×H) | mm | 14100×2750×3750 |
Longitudinal distance between outriggers | m | 6 | |
Transversal distance between outriggers | m | For completely extended outriggers: 7.60 m; | |
For intermediately extended outriggers: 5.04 m | |||
Tail slewing radius | mm | 4020 | |
Main boom length | m | 11.6 - 44.0 | |
Main boom angle | ° | -82 | |
jib length | m | 9.5,16.0 | |
Offset | ° | 0,30 |
1: What kind terms of payment can be accepted? A: For terms of payment, L/C, T/T, D/A, D/P, Western Union (can be) could accepted | ||||||||
2: What certificates are available in Machinery? A: For the certificate, we have CE, ISO, Gost, EPA(USA)CCC, | ||||||||
3: What about the delivery time? A: 7-20 days after receiving the deposit. | ||||||||
4: What about the warranty time? A: 12 months after shipment or 2000 working hours, whichever occuts first. | ||||||||
5. What about the Minimum Order Quantity? A: The MOQ is 1 pcs | ||||||||
