Item | Unit | Parameter | ||
Dimensions (length x width x height) | mm | 14040 * 2790 * 3630 | ||
Total vehicle mass in travel configuration | kg | 40330 | ||
Axle load | 1st and 2nd axle | kg | 16530 | |
3rd and 4th axle | kg | 23800 | ||
Engine model | - | W0615.334 | ||
Engine rated power/rpm | kW/(r/min) | 247/2200 | ||
Max. output torque/rpm | N.m/(r/m1n) | 1350/1100-1600 | ||
Max. travel speed | km/h | 90 | ||
Min. turning diameter | m | 24 | ||
Min. ground clearance | mm | 250 | ||
App roach angle | ° | 18/10 (front protective device included) | ||
Departure angle | ° | 13 | ||
Max. grade ability | % | 38 | ||
Fuel consumption per 100 km | L | 35 | ||
Max. total rated lifting capacity | t | 50 | ||
Min rated working radius | m | 3 | ||
Max. load moment | Base boom | kN.m | 2009 | |
Fully-extended boom | kN.m | 933 | ||
Outrigger span | Longitudinal | m | 6.1 | |
Lateral | m | 7.1 | ||
Hoist height | Base boom | m | 11.2 | |
Fully-extended boom | m | 43.3 | ||
Boom length | Base boom | m | 11.4 | |
Fully-extended boom | m | 43.5 | ||
Jib offset angle | ° | 0、15、 30 | ||
Boom raising time | s | ≤40 | ||
Boom fully extending time | s | ≤90 | ||
Hoistin Hoisting speed (single line, 4th layer, no load) | Main winch | m/min | ≥130 | |
Auxiliary winch | m/min | ≥130 | ||
